SENECA Temp. Transducer Z109PT2
Qty:1pcs The old model is Z109PT,the specifications of product is update as belows:
|
Z109PT |
Z109PT2 |
Power Supply |
19..40Vdc / 19..28 Vac |
9..40 Vdc / 19..28Vac (so also for 12 Vdc) |
Input |
PT100 (field 0.100°C; 0..200°C; 0..400°C) |
Pt100, Pt500,Pt1000, Ni100 (settable on several temperature scales, also for negative values ) |
Wires number |
2,3 |
2,3,4 |
Button for self-learning |
No |
Si |
Accuracy |
0,2% |
0,1% |
Time of answer |
300 ms |
140 ms |
operating temperature |
0..50°C |
-10..+60°C |
|
|
|
|
