Z109PT2 RTD to DC current / voltage isolator converter

This model is update for Z109PT.
■ Power supply: 9..30 (option) - 19..40 Vdc; 19..28 Vac; (50..60 Hz)
■ Input: nr 1 channel by Pt100 2 or 3 wires
■ Output: nr 1 channel, voltage (0..5, 0..10, 1..5, 1..10 V) or current (0..20, 4..20 mA)
■ 3 way galvanic isolation: 1500 Vac
■ Dimensions (w x h x d): 17,5 x 100 x 112 mm


  |
