■ Power supply: 19,2..30 Vdc
■ Input: Nr 1 channel
    - Pt1000, -200..+200 °C, min span 30°C
■ Output: Nr 1 channel, voltage (0..10 / 10..0 / 0..5 / 1.5 V) and current (4..20 / 20..4 / 0..20 / 20..0 mA)
■ Isolation: 1,5 kV (50 Hz, 1 min)
■ Dimensions (w x h x d): 93,1x102,5x6,2 mm


  |
